THE TDR-315N-NEW
The first release from Acclima’s Soil Smart series: demonstrating superb accuracy in a wider range of soils and soilless media.
Fully Integrated TRUE TDR Digital Soil Moisture Sensor.
SOIL SMART:
The latest release from Acclima’s patented range, and the leading product in the Soil Smart series, the TDR-315N answers the call for superior performance in challenging soils, and soilless media.
Throughout extensive testing, the TDR-315N has demonstrated superb accuracy consistently, with excellent repeatability, between six different soils, including potter’s clay.
No other soil moisture sensor on the market matches its accuracy and stability.
Compatible with our RD1200 Handheld Reader.
No external signal generation/processing electronics equipment needed
Costs a fraction of the price of traditional TDRs
TDR accuracy
Convenient SDI-12 Digital output
DATA CAPTURED:
Volumetric Water Content (0 to 100% with 0.1% resolution)
Permittivity (1 to 80 with 0.1 unit resolution)
Bulk EC (0 to 5000 μS/cm - resolution depends on reading range)
Pore Water EC (0 to 55000 μS/cm)
Temperature (- 40 to +60 degrees C with 0.1 degree resolution)
TDR TECHNOLOGY
Widely recognised as the pinnacle of moisture sensing technology, TRUE TDR sensors have always been limited by a number of factors: low portability, bandwidth limiting coaxial lead cable, and high cost (many thousands of dollars).
The founder of Acclima Inc, Scott Anderson has changed all that. Leading years of research refining and miniaturising TDR technology, this year releasing this sensor with all required electronics, algorithms and signal processing contained within the sensor's rugged epoxy resin casing with an industry standard SDI-12 interface.
Highly suited to "insertion style" soil readings making the sensor very user-friendly in the field.
Huge 150ml sample volume - significantly larger than Capacitance probes.
Acclima Reliability
Rugged 316 stainless-steel waveguide. Expected in-service life in excess of 20 years.
LATEST INFO:
TDR-315 Research Paper by Dr Robert Schwartz, USDA
FEATURES:
Large 150 ml soil sample volume
SDI-12 Version 1.3 Interface
Compatible with SDI-12 Data Loggers including Acclima's DataSnap
Derives VWC from ±1% of true permittivity in soils out to 4 dS/m Bulk EC
Soil temperature resolution ±0.2 degree C.
No calibration. Works in ALL soils
No maintenance, simple penetration-style insertion
Linear range of 0-100% volume water content
Moisture readings remain stable as soil salinity, fertiliser content & temperature change
Moisture sense time of <1 second
Very low power, battery operable
5m flexible sheathed cable
